  ACT CARTRIDGE (HR-ACT)

  Medtronic 402-03 ACT PLUS Disposable Test Cartridges 2-Channel Test Cartridges, High Range Activated Clotting Time (HR ACT) – Fresh whole blood test for CV surgery, PTCA, or vascular surgery, Box of 50

  SKU:

  402-03

  Weight:

  3.00 LBS

  Availability:

  2-3 Business days

  Shipping:

  Calculated at checkout

  Quantity:

  123456789101112131415161718192021222324252627282930

  Product Description

  Medtronic 402-03 ACT PLUS Disposable Test Cartridges 2-Channel Test Cartridges,  High Range Activated Clotting Time (HR ACT) – Fresh whole blood test for CV surgery, PTCA, or vascular surgery, Box of 50

                                       ACT PLUS Disposable Test Cartridges 2-Channel Test Cartridges

  402-01	Low Range Activated Clotting Time (LR ACT) – Fresh whole blood test for therapeutic heparin monitoring, post-angioplasty or dialysis	50 per box
  402-02	Recalcified Activated Clotting Time (RACT) – For use with citrated whole blood samples at concentrations of 0.0 – 1.5 u/mL	50 per box
  402-03	High Range Activated Clotting Time (HR ACT) – Fresh whole blood test for CV surgery, PTCA, or vascular surgery	50 per box
  402-07	Heparinase Test Cartridge (HTC) – Fresh whole blood test used to identify the presence of heparin in the patient’s blood sample	20 per box



•

  Rated 3.00 out of 5

  wishlist

  OCTOPUS TISSUE STABILIZER

  Octopus

  Tissue Stabilizers

  OCTOPUS TISSUE STABILIZERS

  Our newest generation tissue stabilizer features automatic pod spread for effective visualization.

  SUMMARY

  OCTOPUS EVOLUTION AS – THE NEXT GENERATION TISSUE STABILIZER

  The newest generation tissue stabiliser from Medtronic demonstrates an enduring commitment to the cardiac surgeon. With all the same features of the Octopus™ Evolution – enhanced stability, flexibility, and a lower profile for unlimited positioning options – the Octopus Evolution AS offers an automatic pod spread feature that enhances visibility at the anastomotic site.

  • Automatic pod spread for effective visualisation of the anastomotic site
  • Very secure arm for maximum stabilization
  • Greater flexibility enables unlimited positioning options
  • Simple, secure, one-handed attachment of clamp to the retractor

  OCTOPUS EVOLUTION – LOW PROFILE WITH FLEXIBILITY AND REACH

  The Octopus Evolution stabilizer provides enhanced stability, flexibility, and a lower profile for unlimited positioning options.

  Enhanced stability and flexibility features:

  • Improved visualisation with:
    • Lower profile headlink
    • Surgeon controlled pod-spread
  • Allowance for multiple device positions including pods-up, pods-down and pods-to-the-side applications
  • Increased flexibility and range of motion
  • Longer, effective reach of the articulating arm provides easier access to all vessels
  • Simple, secure, one-handed engagement of clamp and turret assembly

  THE OCTOPUS 4.3 STABILISER FEATURES SUPERIOR ARM STRENGTH AND UNMATCHED STABILITY IN THE CLAMP/TURRET MECHANISM.

  • Dual vacuum tubes offer superior tissue capture
  • Internal cable enables arm twisting for maximum access and flexibility
  • Reinforced arm links offer better stabilisation
  • Whale tail tightens easily
  • Swivel turret offers access while maximising visualisation
  • Head lock design allows “toes up” position, pod spread and bend
  • Rigid clamp designed to eliminate rocking

  OCTOPUS 4 – EXCELLENT STABILITY AND FLEXIBILITY

  The Octopus 4 tissue stabiliser includes innovative features, such as clear, malleable pods combined with a smaller diameter, more flexible arm, and an ultra-low headlink profile.

  • Pod spreading optimises sewing space and stability of anastomotic site
  • Reduced headlink profile improves visibility of surgical site
  • Rigid, multi-material arm reduces movement at the anastomotic site
  • Smaller diameter, more flexible arm offers greater flexibility in positioning
  • Smaller, color-coded whale tail provides minimal obstruction
  • Single vacuum tubing line minimises obstruction
  • Innovative turret design increases effective arm reach, dramatically increasing positioning options with 360-degree movement
•

  wishlist

  Launcher- 5f Guiding Catheter’s

  EBU@ (Extra Backup)

  LA5EBU30 (EBU 3.0)

  LA5EBU35 (EBU 3.5)

  LA5EBU375 (EBU 3.75)

  LA5EBU40 (EBU 4.0)

  LA5EBU45 (EBU 4.5)

  LA5EBU50 (EBU 5.0)

  JL@ (Judkin Left )

  LA5JL30 (JL 3.0)

  LA5JL35 (JL 3.5)

  LA5JL40 (JL 4.0)

  LA5JL45 (JL 4.5)

  LA5JL50 (JL 5.0)

  LA5JL60 (JL 6.0)

  JR@ (Judkin Right )

  LA5JR30 (JR 3.0)

  LA5JR35 (JR 3.5)

  LA5JR40 (JR 4.0)

  LA5JR45 (JR 4.5)

  LA5JR50 (JR 5.0)

  LA5JR60 (JR 6.0)

  AL@ (Amplatz Left )

  LA5AL75 (AL .75)

  LA5AL10 (AL 1.0)

  LA5AL15 (AL 1.5)

  LA5AL20 (AL 2.0)

  LA5AL25 (AL 2.5)

  LA5AL30 (AL 3.0)

  LA5AL40 (AL 4.0)

  SAL@ (Short Amplatz Left)

  LA5SAL75 (SAL . 75)

  LA5SAL10 (SAL 1.0)

  LA5SAL15 (SAL 1.5)

  LA5SAL20 (SAL 2.0)

  LA5SAL25 (SAL 2.5)

  LA5SAL30 (SAL 3.0)

  LA5SAL40 (SAL 4.0)

  AR@ (Amplatz Right)

  LA5AR10 (AR 1.0)

  LA5AR20 (AR 2.0)

  LA5ALR12 (ALR 1.2)

  ECR Curves@ (Backup Support Right)

  LA5ECR35 (ECR 3.5)

  LA5ECR40 (ECR 4.0)

  LA5ECR45 (ECR 4.5)

  LA5RBU35 (RBU 3.5)

  LA5RBU40 (RBU 4.0)

  SCR@ (Shepherd’s Crook Right)

  LA5SCR35 (SCR 3.5)

  LA5SCR40 (SCR 4.0)

  LA5SCR50 (SCR 5.0)

  SAR@ (Short Amplatz Right)

  LA5SAR10 (SAR 1.0)

  LA5SAR20 (SAR 2.0)

  Multipurpose@

  LA5MB1 (MB 1)

  LA5MB2 (MB 2)

  LA5HSREL (Hockey Stick)

  LA5HSI (Hockey I)

  LA5HSII (Hockey II)

  LA5HSIII (Hockey III)

  Bypass Crafts@

  LA5LCB (LCB)

  LA5RCB (RCB)

  LA5RCB (RCB III)

  LA5RCB (RCB  90cm)

  LA5IMA (IMA)

  LA5IMA (IMA  90cm)



•

  wishlist

  PTCA BALLOON ACCUFORCE

  Description

  Force. Success. No Compromise.

  The great balance between high pressure and high resistance, accurate dilatation and advanced deliverability. Accuforce is the latest generation of non-compliant PTCA balloons.

  Characteristics

  • ​Provides impressive high-pressure resistance up to 22 atm
  • Optimizes (re)crossability and deliverability¹
  • Operates accurately in pre- and post-dilatation

  General specifications

  Shaft diameter	1.9 Fr / 0.64 mm Proximal 2.5 Fr / 0.84 mm Mid 2.6 Fr / 0.86 mm Distal
  Usable length	145 cm
  Balloon markers	2
  Nominal pressure	12 atm / 1216 kPa
  Rated burst pressure	22 atm / 2229 kPa (2.0 mm to 4.0 mm) 20 atm / 2026 kPa (4.5 and 5.0 mm)
  Guidewire compatibility	Maximum diameter 0.014″ / 0.36 mm
  Lesion entry profile	0.43 mm
  Coating	Hydrophilic

  Item specifications

  Ordering Information

  Balloon diameter (mm) ​	Balloon length (mm) / Item references  ​ ​ ​ ​ ​ ​
  	6	8	12	15	20	25	30
  2.00	DC-RM2006HSW	DC-RM2008HSW	DC-RM2012HHW	DC-RM2015HHW	DC-RM2020HHW	—	—
  2.25	DC-RM2206HSW	DC-RM2208HSW	DC-RM2212HHW	DC-RM2215HHW	DC-RM2220HHW	—	—
  2.50	DC-RM2506HSW	DC-RM2508HSW	DC-RM2512HHW	DC-RM2515HHW	DC-RM2520HHW	DC-RM2525HHW	DC-RM2530HHW
  2.75	DC-RM2706HSW	DC-RM2708HSW	DC-RM2712HHW	DC-RM2715HHW	DC-RM2720HHW	—	—
  3.00	DC-RM3006HSW	DC-RM3008HSW	DC-RM3012HHW	DC-RM3015HHW	DC-RM3020HHW	DC-RM3025HHW	DC-RM3030HHW
  3.25	DC-RM3206HSW	DC-RM3208HSW	DC-RM3212HHW	DC-RM3215HHW	DC-RM3220HHW	—	—
  3.50	DC-RM3506HSW	DC-RM3508HSW	DC-RM3512HHW	DC-RM3515HHW	DC-RM3520HHW	DC-RM3525HHW	DC-RM3530HHW
  3.75	DC-RM3706HSW	DC-RM3708HSW	DC-RM3712HHW	DC-RM3715HHW	DC-RM3720HHW	—	—
  4.00	DC-RM4006HSW	DC-RM4008HSW	DC-RM4012HHW	DC-RM4015HHW	DC-RM4020HHW	—	—
  4.50	DC-RM4506HSW	DC-RM4508HSW	DC-RM4512HSW	DC-RM4515HSW	—	—	—
  5.00	DC-RM5006HSW	DC-RM5008HSW	DC-RM5012HSW	DC-RM5015HSW	—	—	—

  Enlarge table

  Please quote above item reference codes when placing an order.

  Balloon Compliance

  Balloon diameter (mm) ​	Pressure (atm) ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​
  	3	4	5	6	7	8	9	10	11	12	13	14	15	16	17	18	19	20	21	22	23	24	25
  2.00	1.58	1.65	1.72	1.79	1.84	1.88	1.92	1.95	1.98	2.00*	2.01	2.03	2.04	2.05	2.06	2.08	2.09	2.10	2.12	2.13**	2.14	2.15	2.17
  2.25	1.96	2.01	2.06	2.11	2.14	2.16	2.19	2.21	2.23	2.25*	2.26	2.28	2.29	2.31	2.32	2.34	2.35	2.36	2.38	2.39**	2.41	2.42	2.44
  2.50	2.19	2.24	2.30	2.36	2.38	2.41	2.44	2.46	2.48	2.50*	2.52	2.53	2.55	2.56	2.58	2.60	2.61	2.63	2.64	2.66**	2.68	2.69	2.71
  2.75	2.43	2.48	2.53	2.59	2.62	2.65	2.67	2.70	2.73	2.75*	2.77	2.79	2.80	2.82	2.84	2.86	2.87	2.89	2.91	2.93**	2.94	2.96	2.98
  3.00	2.65	2.71	2.76	2.82	2.85	2.89	2.92	2.95	2.97	3.00*	3.02	3.04	3.06	3.08	3.10	3.11	3.13	3.15	3.17	3.19**	3.21	3.23	3.25
  3.25	2.89	2.95	3.01	3.07	3.10	3.14	3.17	3.20	3.22	3.25*	3.27	3.29	3.31	3.33	3.35	3.37	3.39	3.42	3.44	3.46**	3.47	3.48	3.51
  3.50	3.13	3.19	3.26	3.32	3.35	3.39	3.42	3.45	3.47	3.50*	3.52	3.54	3.57	3.59	3.61	3.63	3.65	3.68	3.70	3.72**	3.74	3.74	3.76
  3.75	3.37	3.44	3.50	3.56	3.60	3.63	3.66	3.69	3.72	3.75*	3.77	3.80	3.82	3.84	3.86	3.88	3.90	3.92	3.94	3.96**	3.98	3.99	4.01
  4.00	3.58	3.65	3.72	3.79	3.83	3.87	3.90	3.94	3.97	4.00*	4.03	4.05	4.07	4.09	4.11	4.13	4.15	4.17	4.19	4.21**	4.23	4.26	4.28
  4.50	4.02	4.10	4.19	4.28	4.32	4.37	4.40	4.44	4.47	4.50*	4.53	4.56	4.59	4.63	4.66	4.68	4.71	4.75**	4.78	4.81	4.84	4.87	4.91
  5.00	4.52	4.59	4.67	4.75	4.80	4.85	4.89	4.93	4.96	5.00*	5.03	5.07	5.10	5.13	5.16	5.19	5.22	5.26**	5.29	5.32	5.35	5.38	5.41

  Enlarge table

  * Nominal pressure
  ** Rated burst pressure

  References

  ^​​1 Compared with Hiryu. Non-Compliant PTCA Balloon Catheter manufactured by Terumo Corporation.

  Ordering Information. Balloon diameter (mm) ​, Balloon length (mm) / Item references ​ ​ ​ ​ ​ ​.

  Balloon markers: 2

  Usable length: 145 cm

  Coating: Hydrophilic

  Lesion entry profile: 0.43 mm

  Straight-Single Latex Plastic Terumo Accuforce Balloon Catheter, Size: Medium ; Application, Hospital ; Brand, Terumo ; Material, Latex ; Inner Diameter, 36mm.
