  Sprinter OTW Balloon

  Sprinter OTW Semicompliant

  Balloon Dilatation Catheter

  Sprinter™ over-the-wire semicompliant balloon offers low-tip and crossing profiles with a comprehensive size matrix

  OVERVIEW

  The Sprinter™ over-the-wire (OTW) semicompliant balloon dilatation catheter is available in a broad size matrix.

  FEATURES

  MiniWrap folding is used on 1.50-4.00 balloons. The 1.50 mm balloon has two folds.

  1.  Selective Dura-Trac coating
  2.  2.5 mm tip
  3.  FasTrac tip

  Balloon’s

  1. Distal shaft
  2. Gold-swaged marker bands
  3. Selective Dura-Trac hydrophilic coating
  4. Fulcrum balloon material
  5. Proximal shaft (oval)
  6. FasTrac tip
•

  wishlist

  NC Sprinter PTCA BALLOON

  NC Sprinter RX Noncompliant

  NC Stormer over-the-wire noncompliant balloon dilatation catheter offers controlled compliance, high pressures, and comprehensive lengths.

  Balloon Dilatation Catheter

  OVERVIEW

  The NC Sprinter™ RX noncompliant coronary balloon combines:

  • Sprinter crossing technology
  • High-pressure capability and controlled expansion¹

  ORDERING INFORMATION

  BALLOON LENGTHS 6, 9, 12 MM

  Balloon Diameter (mm)	Balloon Length (mm)
  	6	9	12
  2.00	NCSP2006X	NCSP2009X	NCSP2012X
  2.25	NCSP22506X	—	NCSP22512X
  2.50	NCSP2506X	NCSP2509X	NCSP2512X
  2.75	NCSP27506X	NCSP27509X	NCSP27512X
  3.00	NCSP3006X	NCSP3009X	NCSP3012X
  3.25	NCSP32506X	NCSP32509X	NCSP32512X
  3.50	NCSP3506X	NCSP3509X	NCSP3512X
  3.75	NCSP37506X	NCSP37509X	NCSP37512X
  4.00	NCSP4006X	NCSP4009X	NCSP4012X
  4.50	—	—	—
  5.00	—	—	—

  BALLOON LENGTHS 15, 21, 27 MM

  Balloon Diameter (mm)	Balloon Length (mm)
  	15	21	27
  2.00	NCSP2015X	NCSP2021X	—
  2.25	—	NCSP22521X	—
  2.50	NCSP2515X	NCSP2521X	NCSP2527X
  2.75	NCSP27515X	NCSP27521X	—
  3.00	NCSP3015X	NCSP3021X	NCSP3027X
  3.25	NCSP32515X	NCSP32521X	—
  3.50	NCSP3515X	NCSP3521X	NCSP3527X
  3.75	NCSP37515X	NCSP37521X	—
  4.00	NCSP4015X	NCSP4021X	NCSP4027X
  4.50	NCSP4515X	NCSP4521X	—
  5.00	NCSP5015X	—	—

•

  wishlist

  Coronary Diagnostic Catheter (OPTITORQUE)

  PRODUCT OVERVIEW

  A complete line of coronary diagnostic catheters designed for superior torque control and precise placement.

  RADIAL-SPECIFIC UNIVERSAL SHAPES

  • Radial Specific curves designed to enable support and alignment during catheterization¹
  • Excellent back-up support for angiography of both RCA and LCA with a single catheter^1,a
  • Universal design eliminates the need for catheter exchanges and potentially shortens procedural and fluoroscopic time

  _{1. DOF Reference}
  <sup>a. when compared to leading competitors
  2. Ikaria article.</sup>

  OPTITORQUE Classic Shapes

  Shape Category	Product Code 5 Fr / 1.70 mm	Product Code 6 Fr / 2.00 mm	Shape Name (cm)	Length Holes	Side Tip	Shape
  Pigtail	40-5030	40-6030	Straight Pigtail	110	6
  	40-5031	40-6031	Angled Pigtail 155°	110	6
  Judkins Left	40-5040	40-6040	JL 3.5 (Judkins Left 3.5 cm)	100
  	40-5041	40-6041	JL 4.0 (Judkins Left 4.0 cm)	100
  	40-5042	40-6042	JL 5.0 (Judkins Left 5.0 cm)	100
  Judkins Right	40-5043	40-6043	JR 3.5 (Judkins Right 3.5 cm)	100
  	40-5044	40-6044	JR 4.0 (Judkins Right 4.0 cm)	100
  	40-5045		JR 5.0 (Judkins Right 5.0 cm)	100
  Bypass	40-5050	40-6050	Internal Mammary	100
  Amplatz	40-5060		AL 1 (Amplatz Left Small Type)	100
  	40-5061	40-6061	AL 2 (Amplatz Left Middle Type)	100

  UNIQUE DESIGN

  • Designed for coaxial alignment to the ostium, allowing the catheter to sit at the appropriate angle for optimal engagement
  • Large lumen allows high flow of contrast media and allows downsizing of French size

  PROVEN PERFORMANCE

  • Superior torqueability for precise placement^1,a
  • Excellent trackability in tortuous anatomy while navigating the radial artery^1,a
  • Superior flow rates for diagnostic imaging^1,a

  _1.DOF
  ^{a. When compared to leading competitors}

•

  wishlist

  GUIDING CATHETER EKARI

  Product Overview

  IMPROVED BACK UP SUPPORT^*1

  Catheter designed to use contralateral wall resulting in enhanced back-up support.

  UNIVERSAL SHAPE (IKARI LEFT) ^*2

  Offer capability of accessing the right and left coronary arteries, potentially avoiding catheter exchanges.

  DESIGN FOR SAFETY

  Soft tip to reduce damage to the vessel wall



  *1: Ikari Y, Nagaoka M, Kim JY, Merino Y, Tanabe T. The physics of guiding catheters for the left coronary artery in transfemoral and trans-radial interventions. J Invasive Cardio. 2005 Dec; 17(12): 636-641.*2: Youssef AA, Hsieh YK, Cheng CI, We CJ. A single trans-radial guiding catheter for right and left coronary angiography and intervention. Euro intervention 2007; 3: 475-481.

  Patients who have had cardiac catheterization or coronary angioplasty often are required to stay in bed with restricted movement for three to 24 hours afterward to prevent bleeding from the femoral artery catheter insertion site.

  Features and Benefits

  Improved back up support in comparison to Terumo standard femoral guiding catheter shapes^*1



  *1: Based on comparative studies made among Terumo Guiding Catheters*2: Ekari Y, Nagaoka M, Kim JY, Merino Y, Tanabe T. The physics of guiding catheters for the left coronary artery in transfemoral and trans-radial interventions. J Invasive Cardio. 2005 Dec; 17(12): 636-641.*3: Youssef AA, Hsieh YK, Cheng CI, We CJ. A single trans-radial guiding catheter for right and left coronary angiography and intervention. Euro intervention 2007; 3: 475-481.

  Guide catheters are required for all coronary interventions to provide access to the coronary ostium and support equipment delivery. The ideal guide provides stability for device advancement through the coronary anatomy, while minimizing vessel trauma and allowing for vessel opacification.

  The catheter is guided to the narrowed artery. Then, a smaller balloon catheter is inserted through the flexible catheter and inflated at the narrowed area to open it. Often, the doctor will also place a mesh coil called a stent at the narrowed part to help keep the artery open.
