  EUPHORA SEMICOMPLIANT BALLOON CATHETER

  Euphora™ semicompliant balloon

  Balloon Dilatation Catheter

  Euphora™ semicompliant balloon dilatation catheter complements your expertise and provides uncompromising performance in the moment you need it most.

  OVERVIEW

  Advancing Innovation through Partnership

  To develop the Euphora™ low-profile semicompliant balloon dilatation catheter, we partnered with nearly 2,000 interventional cardiologists and cath lab professionals. The result is:

  • Superior deliverability¹
  • Superb Kissing Balloons Technique (KBT) performance²
  • The lowest crossing profile compared to leading competitors³

  PRODUCT DETAILS

  What Makes the Euphora Balloon an Excellent Choice?

  ORDERING INFORMATION

  BALLOON LENGTHS 6, 10, 12, AND 15 MM

  Balloon Diameter (mm)	Balloon Length (mm)
  	6	10	12	15
  1.50	EUP1506X	EUP1510X	EUP1512X	EUP1515X
  2.00	EUP2006X	EUP2010X	EUP2012X	EUP2015X
  2.25	EUP22506X	EUP22510X	EUP22512X	EUP22515X
  2.50	EUP2506X	EUP2510X	EUP2512X	EUP2515X
  2.75	EUP27506X	EUP27510X	EUP27512X	EUP27515X
  3.00	EUP3006X	EUP3010X	EUP3012X	EUP3015X
  3.25	EUP32506X	EUP32510X	EUP32512X	EUP32515X
  3.50	EUP3506X	EUP3510X	EUP3512X	EUP3515X
  3.75	EUP37506X	EUP37510X	EUP37512X	EUP37515X
  4.00	EUP4006X	EUP4010X	EUP4012X	EUP4015X

  BALLOON LENGTHS 20, 25, AND 30 MM

  Balloon Diameter (mm)	Balloon Length (mm)
  	20	25	30
  1.50	EUP1520X	—	—
  2.00	EUP2020X	EUP2025X	EUP2030X
  2.25	EUP22520X	EUP22525X	—
  2.50	EUP2520X	EUP2525X	EUP2530X
  2.75	EUP27520X	EUP27525X	—
  3.00	EUP3020X	EUP3025X	EUP3030X
  3.25	EUP32520X	EUP32525X	—
  3.50	EUP3520X	EUP3525X	EUP3530X
  3.75	EUP37520X	EUP37525X	—
  4.00	EUP4020X	EUP4025X	EUP4030X

•

  wishlist

  FINECROSS Microcatheter

  FINECROSS^® MG Coronary Micro-Guide Catheter

  Product Code	Catheter Length	Distal Hydrophilic Coating	Distal Outer Diameter	Proximal Outer Diameter	Distal Inner Diameter	Proximal Inner Diameter	Recommended Guidewire Size
  35-1430	130cm	70cm	1.8Fr. (0.60mm)	2.6 Fr. (0.87mm)	0.018″ (0.45mm)	0.021″ (0.55mm)	0.014″ (0.36mm)
  35-1450	150cm	90cm	1.8Fr. (0.60mm)	2.6 Fr. (0.87mm)	0.018″ (0.45mm)	0.021″ (0.55mm)	0.014″ (0.36mm)

  PRODUCT OVERVIEW

  Coronary microguide catheter for integration of optimal guidewire support, superior trackability and crossability.^1,2



  TAPERED STAINLESS STEEL BRAID CONSTRUCTION FOR OPTIMAL GUIDEWIRE SUPPORT

  FINECROSS MG stainless steel braid construction is designed to provide strength, responsiveness and support for improved pushability to access and cross complex lesions.

  13cm FLOPPY DISTAL SEGMENT FOR SUPERIOR TRACKABILITY¹

  The distal 13 cm is ultra flexible for improved trackability around tight bends and tortuous anatomy.The floppy distal segment is designed to be atraumatic and provide an optimal balance between trackability and safety while navigating through the tortuous anatomy.¹

  TAPERED OUTER DIAMETER FOR SUPERIOR CROSSABILITY^1,2

  The outer diameter of the stainless steel shaft tapers from a proximal 2.6Fr. to a distal 1.8Fr. designed for improved crossability and guidewire handling.^1,2

  DOCUMENTS

•

  Rated 3.00 out of 5

  wishlist

  OCTOPUS TISSUE STABILIZER

  Octopus

  Tissue Stabilizers

  OCTOPUS TISSUE STABILIZERS

  Our newest generation tissue stabilizer features automatic pod spread for effective visualization.

  SUMMARY

  OCTOPUS EVOLUTION AS – THE NEXT GENERATION TISSUE STABILIZER

  The newest generation tissue stabiliser from Medtronic demonstrates an enduring commitment to the cardiac surgeon. With all the same features of the Octopus™ Evolution – enhanced stability, flexibility, and a lower profile for unlimited positioning options – the Octopus Evolution AS offers an automatic pod spread feature that enhances visibility at the anastomotic site.

  • Automatic pod spread for effective visualisation of the anastomotic site
  • Very secure arm for maximum stabilization
  • Greater flexibility enables unlimited positioning options
  • Simple, secure, one-handed attachment of clamp to the retractor

  OCTOPUS EVOLUTION – LOW PROFILE WITH FLEXIBILITY AND REACH

  The Octopus Evolution stabilizer provides enhanced stability, flexibility, and a lower profile for unlimited positioning options.

  Enhanced stability and flexibility features:

  • Improved visualisation with:
    • Lower profile headlink
    • Surgeon controlled pod-spread
  • Allowance for multiple device positions including pods-up, pods-down and pods-to-the-side applications
  • Increased flexibility and range of motion
  • Longer, effective reach of the articulating arm provides easier access to all vessels
  • Simple, secure, one-handed engagement of clamp and turret assembly

  THE OCTOPUS 4.3 STABILISER FEATURES SUPERIOR ARM STRENGTH AND UNMATCHED STABILITY IN THE CLAMP/TURRET MECHANISM.

  • Dual vacuum tubes offer superior tissue capture
  • Internal cable enables arm twisting for maximum access and flexibility
  • Reinforced arm links offer better stabilisation
  • Whale tail tightens easily
  • Swivel turret offers access while maximising visualisation
  • Head lock design allows “toes up” position, pod spread and bend
  • Rigid clamp designed to eliminate rocking

  OCTOPUS 4 – EXCELLENT STABILITY AND FLEXIBILITY

  The Octopus 4 tissue stabiliser includes innovative features, such as clear, malleable pods combined with a smaller diameter, more flexible arm, and an ultra-low headlink profile.

  • Pod spreading optimises sewing space and stability of anastomotic site
  • Reduced headlink profile improves visibility of surgical site
  • Rigid, multi-material arm reduces movement at the anastomotic site
  • Smaller diameter, more flexible arm offers greater flexibility in positioning
  • Smaller, color-coded whale tail provides minimal obstruction
  • Single vacuum tubing line minimises obstruction
  • Innovative turret design increases effective arm reach, dramatically increasing positioning options with 360-degree movement
•

  wishlist

  PTCA BALLOON ACCUFORCE

  Description

  Force. Success. No Compromise.

  The great balance between high pressure and high resistance, accurate dilatation and advanced deliverability. Accuforce is the latest generation of non-compliant PTCA balloons.

  Characteristics

  • ​Provides impressive high-pressure resistance up to 22 atm
  • Optimizes (re)crossability and deliverability¹
  • Operates accurately in pre- and post-dilatation

  General specifications

  Shaft diameter	1.9 Fr / 0.64 mm Proximal 2.5 Fr / 0.84 mm Mid 2.6 Fr / 0.86 mm Distal
  Usable length	145 cm
  Balloon markers	2
  Nominal pressure	12 atm / 1216 kPa
  Rated burst pressure	22 atm / 2229 kPa (2.0 mm to 4.0 mm) 20 atm / 2026 kPa (4.5 and 5.0 mm)
  Guidewire compatibility	Maximum diameter 0.014″ / 0.36 mm
  Lesion entry profile	0.43 mm
  Coating	Hydrophilic

  Item specifications

  Ordering Information

  Balloon diameter (mm) ​	Balloon length (mm) / Item references  ​ ​ ​ ​ ​ ​
  	6	8	12	15	20	25	30
  2.00	DC-RM2006HSW	DC-RM2008HSW	DC-RM2012HHW	DC-RM2015HHW	DC-RM2020HHW	—	—
  2.25	DC-RM2206HSW	DC-RM2208HSW	DC-RM2212HHW	DC-RM2215HHW	DC-RM2220HHW	—	—
  2.50	DC-RM2506HSW	DC-RM2508HSW	DC-RM2512HHW	DC-RM2515HHW	DC-RM2520HHW	DC-RM2525HHW	DC-RM2530HHW
  2.75	DC-RM2706HSW	DC-RM2708HSW	DC-RM2712HHW	DC-RM2715HHW	DC-RM2720HHW	—	—
  3.00	DC-RM3006HSW	DC-RM3008HSW	DC-RM3012HHW	DC-RM3015HHW	DC-RM3020HHW	DC-RM3025HHW	DC-RM3030HHW
  3.25	DC-RM3206HSW	DC-RM3208HSW	DC-RM3212HHW	DC-RM3215HHW	DC-RM3220HHW	—	—
  3.50	DC-RM3506HSW	DC-RM3508HSW	DC-RM3512HHW	DC-RM3515HHW	DC-RM3520HHW	DC-RM3525HHW	DC-RM3530HHW
  3.75	DC-RM3706HSW	DC-RM3708HSW	DC-RM3712HHW	DC-RM3715HHW	DC-RM3720HHW	—	—
  4.00	DC-RM4006HSW	DC-RM4008HSW	DC-RM4012HHW	DC-RM4015HHW	DC-RM4020HHW	—	—
  4.50	DC-RM4506HSW	DC-RM4508HSW	DC-RM4512HSW	DC-RM4515HSW	—	—	—
  5.00	DC-RM5006HSW	DC-RM5008HSW	DC-RM5012HSW	DC-RM5015HSW	—	—	—

  Enlarge table

  Please quote above item reference codes when placing an order.

  Balloon Compliance

  Balloon diameter (mm) ​	Pressure (atm) ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​
  	3	4	5	6	7	8	9	10	11	12	13	14	15	16	17	18	19	20	21	22	23	24	25
  2.00	1.58	1.65	1.72	1.79	1.84	1.88	1.92	1.95	1.98	2.00*	2.01	2.03	2.04	2.05	2.06	2.08	2.09	2.10	2.12	2.13**	2.14	2.15	2.17
  2.25	1.96	2.01	2.06	2.11	2.14	2.16	2.19	2.21	2.23	2.25*	2.26	2.28	2.29	2.31	2.32	2.34	2.35	2.36	2.38	2.39**	2.41	2.42	2.44
  2.50	2.19	2.24	2.30	2.36	2.38	2.41	2.44	2.46	2.48	2.50*	2.52	2.53	2.55	2.56	2.58	2.60	2.61	2.63	2.64	2.66**	2.68	2.69	2.71
  2.75	2.43	2.48	2.53	2.59	2.62	2.65	2.67	2.70	2.73	2.75*	2.77	2.79	2.80	2.82	2.84	2.86	2.87	2.89	2.91	2.93**	2.94	2.96	2.98
  3.00	2.65	2.71	2.76	2.82	2.85	2.89	2.92	2.95	2.97	3.00*	3.02	3.04	3.06	3.08	3.10	3.11	3.13	3.15	3.17	3.19**	3.21	3.23	3.25
  3.25	2.89	2.95	3.01	3.07	3.10	3.14	3.17	3.20	3.22	3.25*	3.27	3.29	3.31	3.33	3.35	3.37	3.39	3.42	3.44	3.46**	3.47	3.48	3.51
  3.50	3.13	3.19	3.26	3.32	3.35	3.39	3.42	3.45	3.47	3.50*	3.52	3.54	3.57	3.59	3.61	3.63	3.65	3.68	3.70	3.72**	3.74	3.74	3.76
  3.75	3.37	3.44	3.50	3.56	3.60	3.63	3.66	3.69	3.72	3.75*	3.77	3.80	3.82	3.84	3.86	3.88	3.90	3.92	3.94	3.96**	3.98	3.99	4.01
  4.00	3.58	3.65	3.72	3.79	3.83	3.87	3.90	3.94	3.97	4.00*	4.03	4.05	4.07	4.09	4.11	4.13	4.15	4.17	4.19	4.21**	4.23	4.26	4.28
  4.50	4.02	4.10	4.19	4.28	4.32	4.37	4.40	4.44	4.47	4.50*	4.53	4.56	4.59	4.63	4.66	4.68	4.71	4.75**	4.78	4.81	4.84	4.87	4.91
  5.00	4.52	4.59	4.67	4.75	4.80	4.85	4.89	4.93	4.96	5.00*	5.03	5.07	5.10	5.13	5.16	5.19	5.22	5.26**	5.29	5.32	5.35	5.38	5.41

  Enlarge table

  * Nominal pressure
  ** Rated burst pressure

  References

  ^​​1 Compared with Hiryu. Non-Compliant PTCA Balloon Catheter manufactured by Terumo Corporation.

  Ordering Information. Balloon diameter (mm) ​, Balloon length (mm) / Item references ​ ​ ​ ​ ​ ​.

  Balloon markers: 2

  Usable length: 145 cm

  Coating: Hydrophilic

  Lesion entry profile: 0.43 mm
