  Glide sheath

  Product overview

  Expanding trans-radial access to include more patients

  • Glide sheath Slender is designed with a proprietary thin-wall technology where the outside diameter is reduced by one French size while the inner-diameter equivalent is maintained.
  • Glide sheath Slender is coated with Terumo’s proprietary hydrophilic coating, allowing for smooth insertion and removal.



  Features and Benefits



  The proprietary thin-wall technology and Terumo M Coat hydrophilic coating

  • Per the American Heart Association, dedicated radial sheaths with hydrophilic coating combined with smaller diameter sheaths and a tapered tip design may reduce risk of arterial spasm and radial occlusion¹
  • Featuring Terumo’s proprietary hydrophilic coating, the Glide sheath Slender Sheath is the only thin-wall radial sheath on the market to demonstrate superior and consistent performance in lubricity and durability over time

  The Glide sheath Slender Sheath is the only thin-wall sheath that demonstrated best in class performance in all of the American Heart Association’s identified critical features that lead to reduced spasm.



  THE POWER OF TERUMO GLIDE TECHNOLOGY™: LUBRICITY OVER TIMES

  Hydrophilic coating is critical to procedural success, Physicians need to trust that their sheath will be just as lubricous at the end of case as it is at the beginning.

  The graph below demonstrates the results of recent benchtop testing. The lower the value, the more lubricious the coating. The straighter the line, the more consistent, and reliable, the performance.

  Glide sheath Slender Sheath outperformed the other competitive sheaths in both key features: lubricity and lubricity over time.





  Unmatched Clinical Evidence

  • A meta-analysis of 10 clinical papers, involving 3,821 patients, demonstrated that use of Glide sheath Slender Sheath is associated with high rates of procedural success and low rates in performance related issues.
  • In studies measuring patient comfort, patients who underwent percutaneous trans-radial procedures with the Glide sheath Slender Sheath reported none to low amounts of pain.
•

  wishlist

  FINECROSS Microcatheter

  FINECROSS^® MG Coronary Micro-Guide Catheter

  Product Code	Catheter Length	Distal Hydrophilic Coating	Distal Outer Diameter	Proximal Outer Diameter	Distal Inner Diameter	Proximal Inner Diameter	Recommended Guidewire Size
  35-1430	130cm	70cm	1.8Fr. (0.60mm)	2.6 Fr. (0.87mm)	0.018″ (0.45mm)	0.021″ (0.55mm)	0.014″ (0.36mm)
  35-1450	150cm	90cm	1.8Fr. (0.60mm)	2.6 Fr. (0.87mm)	0.018″ (0.45mm)	0.021″ (0.55mm)	0.014″ (0.36mm)

  PRODUCT OVERVIEW

  Coronary microguide catheter for integration of optimal guidewire support, superior trackability and crossability.^1,2



  TAPERED STAINLESS STEEL BRAID CONSTRUCTION FOR OPTIMAL GUIDEWIRE SUPPORT

  FINECROSS MG stainless steel braid construction is designed to provide strength, responsiveness and support for improved pushability to access and cross complex lesions.

  13cm FLOPPY DISTAL SEGMENT FOR SUPERIOR TRACKABILITY¹

  The distal 13 cm is ultra flexible for improved trackability around tight bends and tortuous anatomy.The floppy distal segment is designed to be atraumatic and provide an optimal balance between trackability and safety while navigating through the tortuous anatomy.¹

  TAPERED OUTER DIAMETER FOR SUPERIOR CROSSABILITY^1,2

  The outer diameter of the stainless steel shaft tapers from a proximal 2.6Fr. to a distal 1.8Fr. designed for improved crossability and guidewire handling.^1,2

  DOCUMENTS

•

  wishlist

  NC EUPHORA NONCOMPLIANT BALLOON CATHETER

  NC Euphora™ noncompliant balloon

  NC Euphora™ noncompliant balloon dilatation catheter combines Euphora technology with controlled, high-pressure performance.

  Balloon Dilatation Catheter

  OVERVIEW

  From Collaboration to Innovation

  When it comes to controlled, high-pressure performance, the NC Euphora™ noncompliant balloon dilatation catheter has what you’re looking for:

  • High RBP up to 20 atm
  • Low-growth profile¹
  • Superior deliverability¹

  In fact, we worked with nearly 2,000 interventional cardiologists and cath lab professionals to develop it — so you can choose it with confidence for your patients.

  PRODUCT DETAILS

  Looking for NC Euphora Noncompliant Performance?

  ORDERING INFORMATION

  BALLOON LENGTHS 6, 8, AND 12 MM

  Balloon Diameter (mm)	Balloon Length (mm)
  	6	8	12
  2.00	NCEUP2006X	NCEUP2008X	NCEUP2012X
  2.25	NCEUP22506X	NCEUP22508X	NCEUP22512X
  2.50	NCEUP2506X	NCEUP2508X	NCEUP2512X
  2.75	NCEUP27506X	NCEUP27508X	NCEUP27512X
  3.00	NCEUP3006X	NCEUP3008X	NCEUP3012X
  3.25	NCEUP32506X	NCEUP32508X	NCEUP32512X
  3.50	NCEUP3506X	NCEUP3508X	NCEUP3512X
  3.75	NCEUP37506X	NCEUP37508X	NCEUP37512X
  4.00	NCEUP4006X	NCEUP4008X	NCEUP4012X
  4.50	—	NCEUP4508X	NCEUP4512X
  5.00	—	NCEUP5008X	NCEUP5012X

  BALLOON LENGTHS 15, 20, AND 27 MM

  Balloon Diameter (mm)	Balloon Length (mm)
  	15	20	27
  2.00	NCEUP2015X	NCEUP2020X	—
  2.25	NCEUP22515X	NCEUP22520X	—
  2.50	NCEUP2515X	NCEUP2520X	NCEUP2527X
  2.75	NCEUP27515X	NCEUP27520X	NCEUP27527X
  3.00	NCEUP3015X	NCEUP3020X	NCEUP3027X
  3.25	NCEUP32515X	NCEUP32520X	NCEUP32527X
  3.50	NCEUP3515X	NCEUP3520X	NCEUP3527X
  3.75	NCEUP37515X	NCEUP37520X	NCEUP37527X
  4.00	NCEUP4015X	NCEUP4020X	NCEUP4027X
  4.50	NCEUP4515X	NCEUP4520X	—
  5.00	NCEUP5015X	—	—

•

  wishlist

  EXPORT ADVANCE ASPIRATION CATHETER

  EXPORT ADVANCE ASPIRATION CATHETER

  Export Advance

  Aspiration Catheter

  ADVANCING PERFORMANCE

  The Export Advance™ aspiration catheter delivers consistent, high-performing aspiration power when it matters most — restoring flow and protecting patients.

  PRODUCT DETAILS^†

  Superior Deliverability¹

  Full-Wall Technology provides variable levels of stiffness without joints, for optimal kink resistance and catheter performance.

  Dependable Delivery to the Target Site:

  • Preloaded stylet enhances shaft stiffness during catheter delivery, boosting kink resistance, trackability, and pushability²
  • Buddy wire compatibility allows for extra support, when needed.^†

  High-performing Aspiration Power:

  • Large extraction lumen (0.044″ proximal; 0.043″ distal) increases aspiration power.^‡
  • Optimised hub geometry improves flow.^‡
  • Soft, short, forward-facing tip design permits excellent particle capture.^†

  ---

  ORDERING INFORMATION

  Product Code	Guide Compatibility	Wire Compatibility (in)	Length (cm)
  ADVANCE	6 F min. guide I.D. 0.070″	0.014	140

  • ™Third-party brands are trademarks of their respective owners. All other brands are trademarks of a Medtronic company.

  • Based on bench test data, 2013. Bench test data may not be indicative of clinical performance.
  • Based on bench test data vs. Export™ AP catheter.

  ---

  • Bench testing vs. Terumo Eliminate™* and Eliminate™* 3 aspiration catheters, Vascular Solutions Pronto^®* LP, Pronto^®* V3 and Pronto^®* V4 aspiration catheters, Merit^®* ASAP aspiration catheter, Kaneka Thrombuster III GR* aspiration catheter, Spectranetics QuickCat™* aspiration catheter, IHT Polska Hunter^®* aspiration catheter, Medrad Possis™* Fetch™* 2 aspiration catheter, and Hexacath Recover* aspiration catheter. 10093906DOC, 2013. Bench test data may not be indicative of clinical performance.
  • Based on animal studies compared with Export™ AP aspiration catheter without stylet.
