  OCTOPUS TISSUE STABILIZER

  Octopus

  Tissue Stabilizers

  OCTOPUS TISSUE STABILIZERS

  Our newest generation tissue stabilizer features automatic pod spread for effective visualization.

  SUMMARY

  OCTOPUS EVOLUTION AS – THE NEXT GENERATION TISSUE STABILIZER

  The newest generation tissue stabiliser from Medtronic demonstrates an enduring commitment to the cardiac surgeon. With all the same features of the Octopus™ Evolution – enhanced stability, flexibility, and a lower profile for unlimited positioning options – the Octopus Evolution AS offers an automatic pod spread feature that enhances visibility at the anastomotic site.

  • Automatic pod spread for effective visualisation of the anastomotic site
  • Very secure arm for maximum stabilization
  • Greater flexibility enables unlimited positioning options
  • Simple, secure, one-handed attachment of clamp to the retractor

  OCTOPUS EVOLUTION – LOW PROFILE WITH FLEXIBILITY AND REACH

  The Octopus Evolution stabilizer provides enhanced stability, flexibility, and a lower profile for unlimited positioning options.

  Enhanced stability and flexibility features:

  • Improved visualisation with:
    • Lower profile headlink
    • Surgeon controlled pod-spread
  • Allowance for multiple device positions including pods-up, pods-down and pods-to-the-side applications
  • Increased flexibility and range of motion
  • Longer, effective reach of the articulating arm provides easier access to all vessels
  • Simple, secure, one-handed engagement of clamp and turret assembly

  THE OCTOPUS 4.3 STABILISER FEATURES SUPERIOR ARM STRENGTH AND UNMATCHED STABILITY IN THE CLAMP/TURRET MECHANISM.

  • Dual vacuum tubes offer superior tissue capture
  • Internal cable enables arm twisting for maximum access and flexibility
  • Reinforced arm links offer better stabilisation
  • Whale tail tightens easily
  • Swivel turret offers access while maximising visualisation
  • Head lock design allows “toes up” position, pod spread and bend
  • Rigid clamp designed to eliminate rocking

  OCTOPUS 4 – EXCELLENT STABILITY AND FLEXIBILITY

  The Octopus 4 tissue stabiliser includes innovative features, such as clear, malleable pods combined with a smaller diameter, more flexible arm, and an ultra-low headlink profile.

  • Pod spreading optimises sewing space and stability of anastomotic site
  • Reduced headlink profile improves visibility of surgical site
  • Rigid, multi-material arm reduces movement at the anastomotic site
  • Smaller diameter, more flexible arm offers greater flexibility in positioning
  • Smaller, color-coded whale tail provides minimal obstruction
  • Single vacuum tubing line minimises obstruction
  • Innovative turret design increases effective arm reach, dramatically increasing positioning options with 360-degree movement
•

  wishlist

  Coronary Diagnostic Catheter (OPTITORQUE)

  PRODUCT OVERVIEW

  A complete line of coronary diagnostic catheters designed for superior torque control and precise placement.

  RADIAL-SPECIFIC UNIVERSAL SHAPES

  • Radial Specific curves designed to enable support and alignment during catheterization¹
  • Excellent back-up support for angiography of both RCA and LCA with a single catheter^1,a
  • Universal design eliminates the need for catheter exchanges and potentially shortens procedural and fluoroscopic time

  _{1. DOF Reference}
  <sup>a. when compared to leading competitors
  2. Ikaria article.</sup>

  OPTITORQUE Classic Shapes

  Shape Category	Product Code 5 Fr / 1.70 mm	Product Code 6 Fr / 2.00 mm	Shape Name (cm)	Length Holes	Side Tip	Shape
  Pigtail	40-5030	40-6030	Straight Pigtail	110	6
  	40-5031	40-6031	Angled Pigtail 155°	110	6
  Judkins Left	40-5040	40-6040	JL 3.5 (Judkins Left 3.5 cm)	100
  	40-5041	40-6041	JL 4.0 (Judkins Left 4.0 cm)	100
  	40-5042	40-6042	JL 5.0 (Judkins Left 5.0 cm)	100
  Judkins Right	40-5043	40-6043	JR 3.5 (Judkins Right 3.5 cm)	100
  	40-5044	40-6044	JR 4.0 (Judkins Right 4.0 cm)	100
  	40-5045		JR 5.0 (Judkins Right 5.0 cm)	100
  Bypass	40-5050	40-6050	Internal Mammary	100
  Amplatz	40-5060		AL 1 (Amplatz Left Small Type)	100
  	40-5061	40-6061	AL 2 (Amplatz Left Middle Type)	100

  UNIQUE DESIGN

  • Designed for coaxial alignment to the ostium, allowing the catheter to sit at the appropriate angle for optimal engagement
  • Large lumen allows high flow of contrast media and allows downsizing of French size

  PROVEN PERFORMANCE

  • Superior torqueability for precise placement^1,a
  • Excellent trackability in tortuous anatomy while navigating the radial artery^1,a
  • Superior flow rates for diagnostic imaging^1,a

  _1.DOF
  ^{a. When compared to leading competitors}

•

  wishlist

  NC EUPHORA NONCOMPLIANT BALLOON CATHETER

  NC Euphora™ noncompliant balloon

  NC Euphora™ noncompliant balloon dilatation catheter combines Euphora technology with controlled, high-pressure performance.

  Balloon Dilatation Catheter

  OVERVIEW

  From Collaboration to Innovation

  When it comes to controlled, high-pressure performance, the NC Euphora™ noncompliant balloon dilatation catheter has what you’re looking for:

  • High RBP up to 20 atm
  • Low-growth profile¹
  • Superior deliverability¹

  In fact, we worked with nearly 2,000 interventional cardiologists and cath lab professionals to develop it — so you can choose it with confidence for your patients.

  PRODUCT DETAILS

  Looking for NC Euphora Noncompliant Performance?

  ORDERING INFORMATION

  BALLOON LENGTHS 6, 8, AND 12 MM

  Balloon Diameter (mm)	Balloon Length (mm)
  	6	8	12
  2.00	NCEUP2006X	NCEUP2008X	NCEUP2012X
  2.25	NCEUP22506X	NCEUP22508X	NCEUP22512X
  2.50	NCEUP2506X	NCEUP2508X	NCEUP2512X
  2.75	NCEUP27506X	NCEUP27508X	NCEUP27512X
  3.00	NCEUP3006X	NCEUP3008X	NCEUP3012X
  3.25	NCEUP32506X	NCEUP32508X	NCEUP32512X
  3.50	NCEUP3506X	NCEUP3508X	NCEUP3512X
  3.75	NCEUP37506X	NCEUP37508X	NCEUP37512X
  4.00	NCEUP4006X	NCEUP4008X	NCEUP4012X
  4.50	—	NCEUP4508X	NCEUP4512X
  5.00	—	NCEUP5008X	NCEUP5012X

  BALLOON LENGTHS 15, 20, AND 27 MM

  Balloon Diameter (mm)	Balloon Length (mm)
  	15	20	27
  2.00	NCEUP2015X	NCEUP2020X	—
  2.25	NCEUP22515X	NCEUP22520X	—
  2.50	NCEUP2515X	NCEUP2520X	NCEUP2527X
  2.75	NCEUP27515X	NCEUP27520X	NCEUP27527X
  3.00	NCEUP3015X	NCEUP3020X	NCEUP3027X
  3.25	NCEUP32515X	NCEUP32520X	NCEUP32527X
  3.50	NCEUP3515X	NCEUP3520X	NCEUP3527X
  3.75	NCEUP37515X	NCEUP37520X	NCEUP37527X
  4.00	NCEUP4015X	NCEUP4020X	NCEUP4027X
  4.50	NCEUP4515X	NCEUP4520X	—
  5.00	NCEUP5015X	—	—

•

  wishlist

  PTCA BALLOON ACCUFORCE

  Description

  Force. Success. No Compromise.

  The great balance between high pressure and high resistance, accurate dilatation and advanced deliverability. Accuforce is the latest generation of non-compliant PTCA balloons.

  Characteristics

  • ​Provides impressive high-pressure resistance up to 22 atm
  • Optimizes (re)crossability and deliverability¹
  • Operates accurately in pre- and post-dilatation

  General specifications

  Shaft diameter	1.9 Fr / 0.64 mm Proximal 2.5 Fr / 0.84 mm Mid 2.6 Fr / 0.86 mm Distal
  Usable length	145 cm
  Balloon markers	2
  Nominal pressure	12 atm / 1216 kPa
  Rated burst pressure	22 atm / 2229 kPa (2.0 mm to 4.0 mm) 20 atm / 2026 kPa (4.5 and 5.0 mm)
  Guidewire compatibility	Maximum diameter 0.014″ / 0.36 mm
  Lesion entry profile	0.43 mm
  Coating	Hydrophilic

  Item specifications

  Ordering Information

  Balloon diameter (mm) ​	Balloon length (mm) / Item references  ​ ​ ​ ​ ​ ​
  	6	8	12	15	20	25	30
  2.00	DC-RM2006HSW	DC-RM2008HSW	DC-RM2012HHW	DC-RM2015HHW	DC-RM2020HHW	—	—
  2.25	DC-RM2206HSW	DC-RM2208HSW	DC-RM2212HHW	DC-RM2215HHW	DC-RM2220HHW	—	—
  2.50	DC-RM2506HSW	DC-RM2508HSW	DC-RM2512HHW	DC-RM2515HHW	DC-RM2520HHW	DC-RM2525HHW	DC-RM2530HHW
  2.75	DC-RM2706HSW	DC-RM2708HSW	DC-RM2712HHW	DC-RM2715HHW	DC-RM2720HHW	—	—
  3.00	DC-RM3006HSW	DC-RM3008HSW	DC-RM3012HHW	DC-RM3015HHW	DC-RM3020HHW	DC-RM3025HHW	DC-RM3030HHW
  3.25	DC-RM3206HSW	DC-RM3208HSW	DC-RM3212HHW	DC-RM3215HHW	DC-RM3220HHW	—	—
  3.50	DC-RM3506HSW	DC-RM3508HSW	DC-RM3512HHW	DC-RM3515HHW	DC-RM3520HHW	DC-RM3525HHW	DC-RM3530HHW
  3.75	DC-RM3706HSW	DC-RM3708HSW	DC-RM3712HHW	DC-RM3715HHW	DC-RM3720HHW	—	—
  4.00	DC-RM4006HSW	DC-RM4008HSW	DC-RM4012HHW	DC-RM4015HHW	DC-RM4020HHW	—	—
  4.50	DC-RM4506HSW	DC-RM4508HSW	DC-RM4512HSW	DC-RM4515HSW	—	—	—
  5.00	DC-RM5006HSW	DC-RM5008HSW	DC-RM5012HSW	DC-RM5015HSW	—	—	—

  Enlarge table

  Please quote above item reference codes when placing an order.

  Balloon Compliance

  Balloon diameter (mm) ​	Pressure (atm) ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​
  	3	4	5	6	7	8	9	10	11	12	13	14	15	16	17	18	19	20	21	22	23	24	25
  2.00	1.58	1.65	1.72	1.79	1.84	1.88	1.92	1.95	1.98	2.00*	2.01	2.03	2.04	2.05	2.06	2.08	2.09	2.10	2.12	2.13**	2.14	2.15	2.17
  2.25	1.96	2.01	2.06	2.11	2.14	2.16	2.19	2.21	2.23	2.25*	2.26	2.28	2.29	2.31	2.32	2.34	2.35	2.36	2.38	2.39**	2.41	2.42	2.44
  2.50	2.19	2.24	2.30	2.36	2.38	2.41	2.44	2.46	2.48	2.50*	2.52	2.53	2.55	2.56	2.58	2.60	2.61	2.63	2.64	2.66**	2.68	2.69	2.71
  2.75	2.43	2.48	2.53	2.59	2.62	2.65	2.67	2.70	2.73	2.75*	2.77	2.79	2.80	2.82	2.84	2.86	2.87	2.89	2.91	2.93**	2.94	2.96	2.98
  3.00	2.65	2.71	2.76	2.82	2.85	2.89	2.92	2.95	2.97	3.00*	3.02	3.04	3.06	3.08	3.10	3.11	3.13	3.15	3.17	3.19**	3.21	3.23	3.25
  3.25	2.89	2.95	3.01	3.07	3.10	3.14	3.17	3.20	3.22	3.25*	3.27	3.29	3.31	3.33	3.35	3.37	3.39	3.42	3.44	3.46**	3.47	3.48	3.51
  3.50	3.13	3.19	3.26	3.32	3.35	3.39	3.42	3.45	3.47	3.50*	3.52	3.54	3.57	3.59	3.61	3.63	3.65	3.68	3.70	3.72**	3.74	3.74	3.76
  3.75	3.37	3.44	3.50	3.56	3.60	3.63	3.66	3.69	3.72	3.75*	3.77	3.80	3.82	3.84	3.86	3.88	3.90	3.92	3.94	3.96**	3.98	3.99	4.01
  4.00	3.58	3.65	3.72	3.79	3.83	3.87	3.90	3.94	3.97	4.00*	4.03	4.05	4.07	4.09	4.11	4.13	4.15	4.17	4.19	4.21**	4.23	4.26	4.28
  4.50	4.02	4.10	4.19	4.28	4.32	4.37	4.40	4.44	4.47	4.50*	4.53	4.56	4.59	4.63	4.66	4.68	4.71	4.75**	4.78	4.81	4.84	4.87	4.91
  5.00	4.52	4.59	4.67	4.75	4.80	4.85	4.89	4.93	4.96	5.00*	5.03	5.07	5.10	5.13	5.16	5.19	5.22	5.26**	5.29	5.32	5.35	5.38	5.41

  Enlarge table

  * Nominal pressure
  ** Rated burst pressure

  References

  ^​​1 Compared with Hiryu. Non-Compliant PTCA Balloon Catheter manufactured by Terumo Corporation.

  Ordering Information. Balloon diameter (mm) ​, Balloon length (mm) / Item references ​ ​ ​ ​ ​ ​.

  Balloon markers: 2

  Usable length: 145 cm

  Coating: Hydrophilic

  Lesion entry profile: 0.43 mm

  Straight-Single Latex Plastic Terumo Accuforce Balloon Catheter, Size: Medium ; Application, Hospital ; Brand, Terumo ; Material, Latex ; Inner Diameter, 36mm.
