  FINECROSS Microcatheter

  FINECROSS^® MG Coronary Micro-Guide Catheter

  Product Code	Catheter Length	Distal Hydrophilic Coating	Distal Outer Diameter	Proximal Outer Diameter	Distal Inner Diameter	Proximal Inner Diameter	Recommended Guidewire Size
  35-1430	130cm	70cm	1.8Fr. (0.60mm)	2.6 Fr. (0.87mm)	0.018″ (0.45mm)	0.021″ (0.55mm)	0.014″ (0.36mm)
  35-1450	150cm	90cm	1.8Fr. (0.60mm)	2.6 Fr. (0.87mm)	0.018″ (0.45mm)	0.021″ (0.55mm)	0.014″ (0.36mm)

  PRODUCT OVERVIEW

  Coronary microguide catheter for integration of optimal guidewire support, superior trackability and crossability.^1,2



  TAPERED STAINLESS STEEL BRAID CONSTRUCTION FOR OPTIMAL GUIDEWIRE SUPPORT

  FINECROSS MG stainless steel braid construction is designed to provide strength, responsiveness and support for improved pushability to access and cross complex lesions.

  13cm FLOPPY DISTAL SEGMENT FOR SUPERIOR TRACKABILITY¹

  The distal 13 cm is ultra flexible for improved trackability around tight bends and tortuous anatomy.The floppy distal segment is designed to be atraumatic and provide an optimal balance between trackability and safety while navigating through the tortuous anatomy.¹

  TAPERED OUTER DIAMETER FOR SUPERIOR CROSSABILITY^1,2

  The outer diameter of the stainless steel shaft tapers from a proximal 2.6Fr. to a distal 1.8Fr. designed for improved crossability and guidewire handling.^1,2

  DOCUMENTS

•

  wishlist

  Coronary Diagnostic Catheter (OPTITORQUE)

  PRODUCT OVERVIEW

  A complete line of coronary diagnostic catheters designed for superior torque control and precise placement.

  RADIAL-SPECIFIC UNIVERSAL SHAPES

  • Radial Specific curves designed to enable support and alignment during catheterization¹
  • Excellent back-up support for angiography of both RCA and LCA with a single catheter^1,a
  • Universal design eliminates the need for catheter exchanges and potentially shortens procedural and fluoroscopic time

  _{1. DOF Reference}
  <sup>a. when compared to leading competitors
  2. Ikaria article.</sup>

  OPTITORQUE Classic Shapes

  Shape Category	Product Code 5 Fr / 1.70 mm	Product Code 6 Fr / 2.00 mm	Shape Name (cm)	Length Holes	Side Tip	Shape
  Pigtail	40-5030	40-6030	Straight Pigtail	110	6
  	40-5031	40-6031	Angled Pigtail 155°	110	6
  Judkins Left	40-5040	40-6040	JL 3.5 (Judkins Left 3.5 cm)	100
  	40-5041	40-6041	JL 4.0 (Judkins Left 4.0 cm)	100
  	40-5042	40-6042	JL 5.0 (Judkins Left 5.0 cm)	100
  Judkins Right	40-5043	40-6043	JR 3.5 (Judkins Right 3.5 cm)	100
  	40-5044	40-6044	JR 4.0 (Judkins Right 4.0 cm)	100
  	40-5045		JR 5.0 (Judkins Right 5.0 cm)	100
  Bypass	40-5050	40-6050	Internal Mammary	100
  Amplatz	40-5060		AL 1 (Amplatz Left Small Type)	100
  	40-5061	40-6061	AL 2 (Amplatz Left Middle Type)	100

  UNIQUE DESIGN

  • Designed for coaxial alignment to the ostium, allowing the catheter to sit at the appropriate angle for optimal engagement
  • Large lumen allows high flow of contrast media and allows downsizing of French size

  PROVEN PERFORMANCE

  • Superior torqueability for precise placement^1,a
  • Excellent trackability in tortuous anatomy while navigating the radial artery^1,a
  • Superior flow rates for diagnostic imaging^1,a

  _1.DOF
  ^{a. When compared to leading competitors}

•

  wishlist

  RADIFOCUS REDIAL SHEATH

  Providing you the best range of Terumo Radifocus Radial Introducer Sheath and Cordis Femoral Introducer Sheath with effective & timely delivery.

  The radial artery access sheath is used to gain arterial access and facilitate the insertion of catheters or other equipment for diagnostic and vascular interventions.

  • The Cordis AVANTI®+ Introducer is the pioneer of catheter sheath introducer technology. Featuring a patented SLIX Valve, the AVANTI®+ introducer provides smooth transitions, monitoring capabilities and exceptional performance for your procedural success, as well as
  • A hexacuspid design that provides a balance between catheter maneuverability and hemostasis.
  • A rotating suture collar that facilitates procedural flexibility. It stays in place and allows patient movement.
  • A kink-resistant cannula design integrating a soft, flexible inner layer with a stiffer outer layer designed to increase bendability and support, and decrease kinking.
  • Atraumatic tip transitions for both the sheath and the vessel dilator are uniquely tapered and manicured. This results in smooth insertions and helps to minimize damage upon entry.

  As part of the circulatory system, the radial artery supplies blood from the heart to the forearm.

  Radial sheaths had the smallest OD (1 Fr smaller) when compared to similar sized conventional sheaths. For instance, the OD of 4 Fr radial sheath (1.610 ± 0.006 mm) is essentially the same as the OD of the conventional 3 Fr (1.644 ± 0.016 mm) and 3.3 Fr (1.635 ± 0.005 mm) sheaths.

•

  wishlist

  RADIFOCUS INTRODUCER  SHEATH

  Radifocus™ Introducer II Standard Kit A

  Introducer Sheath (FEMORAL)

  Kit of vascular introducer with hemostatic valve with excellent blood tightness,
  easy and non traumatic vessel insertion, patented valve design for a unique
  features package.

  • Total Integrated Fit (TIF) tip tapering: tapering design at the tip of the sheath and dilator to facilitate smooth penetration
  • Cross-cut hemostasis valve to avoid blood reflux and air aspiration
  • Thin radiopaque sheath with anti-kinking sleeve for easy catheter handling
  • Snap-on/click-off dilator lock prevents dilator back-out during insertion and allows one-hand unlocking
  • Wide variety of kit variations providing all elements for quick vessel access:  4-11 Fr  sheaths, 5-16 cm lengths, Surf lash needle

  General specifications

  Sheath length	10 cm
  Mini guidewire	Plastic Straight and Angled 0.025″ (0.64 mm) for 4 Fr, straight mini guidewire type; 0.035″ (0.89 mm) for all others 45 cm
  Entry needle	Plastic IV Catheter – 18G x 2 ½” (1.2 x 64 mm), except for 4 Fr with 45 cm straight mini guidewire: 20G x 2″ (0.9 x 51 mm) 2.5 ml syringe is included
  Guidewire compatibility	0.025″ (0.64 mm) for 4 Fr, straight mini guidewire type 0.035″ (0.89 mm) for all others
  Packaging	Tray
  ​A Kit content	​Sheath, dilator, plastic mini guidewire and plastic IV catheter (entry needle)



  Item specifications

  Inner diameter ​	Mini guidewire type ​
  	45 cm angled	45 cm straight
  4 Fr	RS+A40K10AQ	RS+A40G10SQ
  ​4 Fr	​RS*A40G10SQ	​RS*A40G05SQ
  ​4 Fr	​RS*A40K10SQ	​RS*A40G07SQ
  ​5 Fr	​RS*A50K10AQ	​RS*A50G07SQ
  5 Fr	RS+A50K10AQ	RS+A50K10SQ
  6 Fr	RS+A60K10AQ	RS+A60K10SQ
  ​6 Fr	RS*A60K10AQ	​RS*A60G07SQ
  6 Fr​	​—	​RS*A60G16SQZ
  ​6 Fr	​—	​RS*A60K10SQ
  ​6 Fr	​—	​RS+A50K10SQ
  7 Fr	—	RS+A70K10SQ
  ​7 Fr	​—	​RS*A70G07SQ
  ​7 Fr	—​	​RS*A70K10SQ
  8 Fr	—​	RS+A80K10SQ
  ​8 Fr	​—	​RS*A80K10SQ
  9 Fr	—	RS*A90K10SQ
  10 Fr	—	RS*A10K10SQ
  11 Fr	—	RS*A11K10SQ

  A Kit includes: introducer sheath, dilator, mini Guide wire, entry venous catheter, 2.5 cc syringe
  B Kit includes: introducer sheath, dilator, mini Guide wire
  C Kit includes: introducer sheath, dilator
  R Kit includes: introducer sheath, dilator, mini Guide wire, 18 G x 2 3/4” / 1.2 x 70 mm entry metallic needle
  Other code numbers are available on special demand. For any further information, please contact your Terumo local representative
  Units per box: 5 for kits in tray and 10 for kits in pouch.
