Related products

•

  wishlist

  NC Sprinter PTCA BALLOON

  NC Sprinter RX Noncompliant

  NC Stormer over-the-wire noncompliant balloon dilatation catheter offers controlled compliance, high pressures, and comprehensive lengths.

  Balloon Dilatation Catheter

  OVERVIEW

  The NC Sprinter™ RX noncompliant coronary balloon combines:

  • Sprinter crossing technology
  • High-pressure capability and controlled expansion¹

  ORDERING INFORMATION

  BALLOON LENGTHS 6, 9, 12 MM

  Balloon Diameter (mm)	Balloon Length (mm)
  	6	9	12
  2.00	NCSP2006X	NCSP2009X	NCSP2012X
  2.25	NCSP22506X	—	NCSP22512X
  2.50	NCSP2506X	NCSP2509X	NCSP2512X
  2.75	NCSP27506X	NCSP27509X	NCSP27512X
  3.00	NCSP3006X	NCSP3009X	NCSP3012X
  3.25	NCSP32506X	NCSP32509X	NCSP32512X
  3.50	NCSP3506X	NCSP3509X	NCSP3512X
  3.75	NCSP37506X	NCSP37509X	NCSP37512X
  4.00	NCSP4006X	NCSP4009X	NCSP4012X
  4.50	—	—	—
  5.00	—	—	—

  BALLOON LENGTHS 15, 21, 27 MM

  Balloon Diameter (mm)	Balloon Length (mm)
  	15	21	27
  2.00	NCSP2015X	NCSP2021X	—
  2.25	—	NCSP22521X	—
  2.50	NCSP2515X	NCSP2521X	NCSP2527X
  2.75	NCSP27515X	NCSP27521X	—
  3.00	NCSP3015X	NCSP3021X	NCSP3027X
  3.25	NCSP32515X	NCSP32521X	—
  3.50	NCSP3515X	NCSP3521X	NCSP3527X
  3.75	NCSP37515X	NCSP37521X	—
  4.00	NCSP4015X	NCSP4021X	NCSP4027X
  4.50	NCSP4515X	NCSP4521X	—
  5.00	NCSP5015X	—	—

•

  Rated 1.00 out of 5

  wishlist

  Sprinter OTW Balloon

  Sprinter OTW Semicompliant

  Balloon Dilatation Catheter

  Sprinter™ over-the-wire semicompliant balloon offers low-tip and crossing profiles with a comprehensive size matrix

  OVERVIEW

  The Sprinter™ over-the-wire (OTW) semicompliant balloon dilatation catheter is available in a broad size matrix.

  FEATURES

  MiniWrap folding is used on 1.50-4.00 balloons. The 1.50 mm balloon has two folds.

  1.  Selective Dura-Trac coating
  2.  2.5 mm tip
  3.  FasTrac tip

  Balloon’s

  1. Distal shaft
  2. Gold-swaged marker bands
  3. Selective Dura-Trac hydrophilic coating
  4. Fulcrum balloon material
  5. Proximal shaft (oval)
  6. FasTrac tip
•

  Rated 4.00 out of 5

  wishlist

  PTCA Balloon Ryurei

  Description

  Confidence in your hands

  Ryurei™ has superior crossability¹ thanks to the combination of low distal profiles and Terumo’s hydrophilic M coating. The short balloon bonding and reinforced shaft¹ results in enhanced trackability¹ while maintaining excellent pushability¹.

  These features can increase physician’s confidence in success even during complex procedures.

  Characteristics

  Excellent Pusability

  The combination of flexible distal part,  tapered core wire on the midshaft and the thick proximal hypotube, results in smooth and balanced transition across the entire catheter for high transmission force, resulting in excellent pushability

  Superior Crossability²

  Thanks to the combination of distal  low profiles and the Terumo hydrophilic M-Coat, Ryurei offers low friction in crossing tight lesions

  Enhanced Trackability²

  With an optimal tip design and improved balloon bonding, Ryurei provides enhanced trackability, even in tortuous anatomy and difficult to navigate vessels.





  General specifications

  ​Shaft diameter	​1.9 Fr/0.64 mm Proximal • 2.5 Fr/0.84 mm Middle • 2.4 Fr/0.79 mm to 2.7 Fr/0.89 mm (tapered) Distal (1.00 to 1.50 mm) • 2.6 Fr/0.87 mm Distal (2.00 to 4.00 mm)
  ​Usable length	​145 cm
  ​Balloon markers #	​1(Ø1.0 to Ø 1.5 mm) • 2(Ø2.0 to Ø4.0 mm)
  ​Nominal pressure	​6 atm / 608 kPa
  ​Rated burst pressure	Ø1.0 – 3.0 mm=14 atm(1419kPa) • Ø3.25 – 4.0 mm = 12 atm(1216 kPa)
  ​Guidewire compatibility	​Maximum diameter: 0.014″ / 0.36 mm
  ​Lesion entry profile	​0.41 mm (Ø1.00 to Ø1.50 mm) • 0.43 mm (Ø2.00 to Ø4.00 mm)
  ​Coating	​Hydrophilic

  Item specifications

  Balloon length / Product code​ ​ ​ ​ ​ ​ ​
  Balloon Diameter	5 mm	10 mm	15 mm	20 mm	30 mm	40 mm
  1.00 mm	DC-RR1005HH
  ​1.25 mm	​DC-RR1205HH	​​DC-RR1210HH	​​DC-RR1215HH	​​DC-RR1220HH	​	​
  1.50 mm	DC-RR1505HH	DC-RR1510HH	DC-RR1515HH	DC-RR1520HH
  2.00 mm		DC-RR2010HHW	DC-RR2015HHW	DC-RR2020HHW	DC-RR2030HHW	DC-RR2040HHW
  2.25 mm		DC-RR2210HHW	DC-RR2215HHW	DC-RR2220HHW
  2.50 mm		DC-RR2510HHW	DC-RR2515HHW	DC-RR2520HHW	DC-RR2530HHW	DC-RR2540HHW
  2.75 mm		DCRR2710HHW	DC-RR2715HHW	DC-RR2720HHW
  3.00 mm		DC-RR3010HHW	DC-RR3015HHW	DC-RR3020HHW	DC-RR3030HHW	DC-RR3040HHW
  3.25 mm		DC-RR3210HHW	DC-RR3215HHW	DC-RR3220HHW
  3.50 mm		DC-RR3510HHW	DC-RR3515HHW	DC-RR3520HHW	DC-RR3530HHW	DC-RR3540HHW
  3.75 mm		DC-RR3710HHW	DC-RR3715HHW	DC-RR3720HHW
  4.00 mm		DC-RR4010HHW	DC-RR4015HHW	DC-RR4020HHW

  References

  ¹ Ryurei φ1.00-5mm compared to Tazuna 1.25-10 mm- Data on file ISCD-416-31-4
  * For Ryurei Ø 1.00 mm – Ø 1.50 mm.
  ** For Ryurei Ø 1.00mm – 5mm ​



  ² Compared to Tazuna PTCA dilatation catheter

•

  wishlist

  Launcher- 7f Guiding Catheter’s

  EBU@ (Extra Backup)

  LA7EBU30 (EBU 3.0)

  LA7EBU35 (EBU 3.5)

  LA7EBU375 (EBU 3.75)

  LA7EBU40 (EBU 4.0)

  LA7EBU45 (EBU 4.5)

  LA7EBU50 (EBU 5.0)

  JL@ (Judkin Left )

  LA7JL30 (JL 3.0)

  LA7JL35 (JL 3.5)

  LA7JL40 (JL 4.0)

  LA7JL45 (JL 4.5)

  LA7JL50 (JL 5.0)

  LA7JL60 (JL 6.0)

  JR@ (Judkin Right )

  LA7JR30 (JR 3.0)

  LA7JR35 (JR 3.5)

  LA7JR40 (JR 4.0)

  LA7JR45 (JR 4.5)

  LA7JR50 (JR 5.0)

  LA7JR60 (JR 6.0)

  AL@ (Amplatz Left )

  LA7AL75 (AL .75)

  LA7AL10 (AL 1.0)

  LA7AL15 (AL 1.5)

  LA7AL20 (AL 2.0)

  LA7AL25 (AL 2.5)

  LA7AL30 (AL 3.0)

  LA7AL40 (AL 4.0)

  SAL@ (Short Amplatz Left)

  LA7SAL75 (SAL . 75)

  LA7SAL10 (SAL 1.0)

  LA7SAL15 (SAL 1.5)

  LA7SAL20 (SAL 2.0)

  LA7SAL25 (SAL 2.5)

  LA7SAL30 (SAL 3.0)

  LA7SAL40 (SAL 4.0)

  AR@ (Amplatz Right)

  LA7AR10 (AR 1.0)

  LA7AR20 (AR 2.0)

  LA7ALR12 (ALR 1.2)

  ECR Curves@ (Backup Support Right)

  LA7ECR35 (ECR 3.5)

  LA7ECR40 (ECR 4.0)

  LA7ECR45 (ECR 4.5)

  LA7RBU35 (RBU 3.5)

  LA7RBU40 (RBU 4.0)

  SCR@ (Shepherd’s Crook Right)

  LA7SCR35 (SCR 3.5)

  LA7SCR40 (SCR 4.0)

  LA7SCR50 (SCR 5.0)

  SAR@ (Short Amplatz Right)

  LA7SAR10 (SAR 1.0)

  LA7SAR20 (SAR 2.0)

  Multipurpose@

  LA7MB1 (MB 1)

  LA7MB2 (MB 2)

  LA7HSREL (Hockey Stick)

  LA7HSI (Hockey I)

  LA7HSII (Hockey II)

  LA7HSIII (Hockey III)

  Bypass Crafts@

  LA7LCB (LCB)

  LA7RCB (RCB)

  LA7RCB (RCB III)

  LA7RCB (RCB  90cm)

  LA7IMA (IMA)

  LA7IMA (IMA  90cm)
